| Product introduct |
G/EPON 1GE+1FE+WiFi+CATV ONU meets telecom operators FTTO (office), FTTD (Desk) ,FTTH(Home) broadband speed, SOHO broadband access, video surveillance and other requirements to design an EPON/GPON Gigabit Ethernet products. It is based on mature and stable, cost-effective EPON/GPON technology, high reliability, easy management, configuration flexibility and good quality of service (QoS) guarantees to meet the technical performance of IEEE802.3ah and ITU-TG.984.x , China Telecom EPON/GPON equipment technical requirements and other specifications.
| Function parameter |
| Technical item | 1GE+1FE+1POTS |
| PON interface | 1 G/EPON port(EPON PX20+ and GPON Class B+) Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM |
| Wavelength | Tx1310nm,Rx 1490nm |
| Optical interface | SC/UPC connector |
| LAN interface | 1 x 10/100/1000Mbps and 1 x 10/100Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector |
| POTS interface | 1 FXS, RJ11 connectors Support: G.711/G.723/G.726/G.729 codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according to GR-909 |
| LED | 8, For Status of POWER、LOS、PON、LAN1、LAN2、PHONE、Pair、 WiFi |
| Operating condition | Temperature: 0℃～+50℃ Humidity: 10%～90%（non-condensing） |
| Storing condition |
Temperature: -30℃～+60℃ Humidity: 10%～90%（non-condensing） |
| Power supply | DC 12V/1A |
| Power supply | ≤6W |
| Dimension | 185mm×120mm×34mm（L×W×H） |
| Net weight | 0.24Kg |
| Typical application diagram |
