| Item | V1600D4-L | |
| Chassis | Rack | 1U Height Box |
| Uplink Port | Port count | 4 |
| GE(RJ45) | 2*10/100/1000M auto-negotiation | |
| GE(SFP) | 2 | |
| EPON Port | QTY | 4 |
| Physical Interface | SFP Slots | |
| Connector Type | PX20++/PX20+++ | |
| Max splitting ratio | 1:64 | |
| Backplane Bandwidth (Gbps) | 20 | |
| Port Forwarding Rate(Mpps) | 11.904 | |
| Dimension (LxWxH) | 442mm*200mm*43.6mm | |
| Weight | 4.2kg | |
| Power Supply | AC:90~264V, 47/63Hz, Support Redundant Power | |
| Power Consumption | 30W | |
| Operating Environment | Working Temperature | -10~+50°C |
| Storage Temperature | -40~+85°C | |
| Relative Humidity | 5~90% (non-condensing) | |
