VSOL 1 GE XPON ONT

Name: VSOL 1 GE XPON ONT
Brand: V-Solution Indonesia
SKU: V2801SG
Availability: InStock
Rating: 5 (1 reviews)

Item No.: V2801SG

V2801SG ( XPON 1GE ONU ) dirancang khusus untuk memenuhi kebutuhan operator telekomunikasi untuk FTTO (kantor), FTTD (desktop), FTTH (rumah), akses broadband SOHO, pengawasan video, dll. ONT didasarkan pada chip berkinerja tinggi solusi teknologi, dan mendukung fungsi Layer 2/Layer 3, menyediakan layanan data untuk aplikasi FTTH tingkat operator.

ONT memiliki keandalan yang tinggi dan dapat diterapkan pada lingkungan bersuhu luas; dan memiliki fungsi firewall yang kuat, yang mudah dikelola dan dipelihara. Ini dapat memberikan jaminan QoS untuk layanan yang berbeda. ONT mematuhi standar teknis internasional seperti IEEE802.3ah dan ITU-T G.984.

Material: ABS Plastic

Size: 82mm×82mm×25mm

Weight: 85g

INQUIRY

Description parameters Product videos Download

VSOL 1 GE XPON ONT

XPON Dual Mode | Prevent Rogue ONT | Wide Temp Design | Security ONT

Support HGU/SFU Feature, Flexible Access Network

Support Bridge Mode & Router Mode

Wide-Working-Temperature Designed

Long time stable connection

Make Your Network More Secure

○ Hardware Parameter
Dimension	82mm×82mm×25mm(L×W×H)
Net weight	85g
Operating condition	Operating Temp: -30 ~ +70°C Operating Humidity: 10 ~ 90%(non-condensed)
Storing condition	Storing temp: -30 ~ +70°C Storing humidity: 10 ~ 90% (non-condensed)
Power adapter	DC 12V, 0.5A, external AC-DC power adaptor
Power supply	≤4W
Interface	1GE
Indicators	SYS, LINK/ACT, REG

○ Interface parameter
PON interface	1XPON port(EPON PX20+ and GPON Class B+) SC single mode, SC/UPC connector TX optical power: 0～+4dBm RX sensitivity: -27dBm Overload optical power: -3dBm(EPON) or -8dBm(GPON) Transmission distance: 20KM Wavelength: TX 1310nm, RX1490nm
LAN interface	1*GE, Auto-negotiation RJ45 connectors

○ Function Data
XPON Mode	Dual mode,Auto-access to EPON/GPON OLT
Uplink Mode	Bridging and Routing Mode
Abnormal protection	Detecting Rogue ONU, Hardware Dying Gasp
Firewall	DDOS, Filtering Based on ACL/MAC/URL

○ Product Feature
Basic	Support MPCP discover®ister Support authentication Mac/Loid/Mac+Loid Support Triple Churning Support DBA bandwidth Support auto-detecting, auto-configuration, and auto firmware upgrade Support SN/Psw/Loid/Loid+Psw authentication
Alarm	Support Dying Gasp Support Port Loop Detect Support Eth Port Los
LAN	Support Port rate limiting Support Loop detection Support Flow control Support Storm control
VLAN	Support VLAN tag mode Support VLAN transparent mode Support VLAN trunk mode(max 8 vlans) Support VLAN 1:1 translation mode(≤8 vlans) Auto VLAN detection
Multicast	Support IGMP v1/v2/Snooping Max Multicast vlan 8 Max Multicast Group 64
QOS	Support 4 queues Support SP and WRR Support 802.1P
L3	Support IPv4 Support DHCP/PPPOE/Static IP Support Static route Support NAT
Management	Support CTC OAM 2.0 and 2.1 Support ITUT984.x OMCI Support WEB Support TELNET Support CLI

Datasheet

XPON ONT V2801SG&V2801RD Datasheet-V2.0-EN
