1GE+1POTS HGU

Name: 1GE+1POTS HGU
Brand: V-Solution Indonesia
SKU: HG322G
Availability: InStock
Rating: 5 (1 reviews)

Item No.: HG322G

Perangkat terminal 1GE+1POTS XPON HGU dirancang untuk memenuhi permintaan layanan FTTH dan triple play dari operator jaringan tetap.

Material: ABS Plastic

Size: 100mm*92mm*29.5mm(L×W×H)

Weight: 110g

INQUIRY

Description parameters Download

HG322G Gigabit ONT

HGU ONU

HGU Router

○ Hardware Parameter
Dimension	100mm92mm29.5mm(L×W×H)
Net weight	110g
Operating condition	Operating temp: 0 ~ +55°C Operating humidity: 10~90% (non-condensed)
Storing condition	Storing temp: -30 ~ +60°C Storing humidity: 10 ~ 90% (non-condensed)
Power adapter	DC 12V/1A, external AC-DC power adaptor
Power supply	≤10W
Interface	1GE+1POTS
Indicators	PWR, PON, LOS, WAN, LAN, PHONE

○ Interface parameter
PON interface	1XPON port(EPON PX20+ and GPON Class B+) SC single mode, SC/UPC connector TX optical power: 0～+4dBm RX sensitivity: -27dBm Overload optical power: -3dBm(EPON) or -8dBm(GPON) Transmission distance: 20KM Wavelength: TX 1310nm, RX1490nm
User interface	1GE, Auto-negotiation,RJ45 ports 1POTS RJ11 Connector

○ Function Data
Management	OAM/OMCI, Telnet, WEB, TR069 Support full management of HGU functions by VSOL OLT
Multicast	Support IGMP v1/v2/v3 Support IGMP Proxy and MLD Proxy Support IGMP Snooping and MLD Snooping
Internet connection	Support Bridge, Route and Bridge/Route mixed mode
VLAN	Support VLAN tag mode Support VLAN trunk mode Support VLAN translation
Data Service Functions	Full speed non-blocking switching 2K MAC address table 4K VLAN ID Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc Support auto polarity detection of Ethernet ports (AUTO MDIX) Integrated IEEE802.1p QoS with four level priority queues Support IGMP v1/v2/v3 snooping/proxy and MLD v1/v2 snooping/proxy
VoIP	SIP and IMS SIP Codec∶G.711/G.723/G.726/G.729 codec Echo cancellation,VAD/CNG,DTMF T.30/T.38 FAX Caller Identification/Call Waiting/Call Forwarding/Call Transfer/Call Hold/3-way Conference Line testing according to GR-909
QoS	Support 4 queues Support SP and WRR Support 802.1P and DSCP
L3	Support IPv4, IPv6 and IPv4/IPv6 dual stack Support DHCP/PPPOE/Static Support Static route Support DHCP Server Support NAT/DMZ/DDNS Support Virtual Server
Security	Support Firewall Support Mac filter Based on MAC or URL Support ACL
