| ○ Technical Parameter | |
| Chip Platform | ASR1803s+ASR5803W |
| Frequent Band | FDD LTE: B1/B3/B5/B7/B8/B20/B28 TDD LTE: B38/B40/B41 UMTS: B1/B5/B8 |
| Protocol Version | 4G: 3GPP R9 Cat4 + 3G: 3GPP R7 |
| Data Rate | FDD：DL/UL up to 150Mbps/50Mbps TDD： DL/UL up to 110Mbps/10Mbps 3G: DL/UL up to 21Mbps/5.76Mbps |
| WiFi Standard | 802.11 b/g/n, 1*antenna, 72.2Mbps |
| Size | 150×105×30mm(L×W×H) |
| Weight | 230g |
| Power Supply | DC 12V,1A |
| Physical Interface | 1*RJ45(100M, 1 LAN)，1*4FF USIM, 1*DC Input Port |
| LED | POWER, WiFi, LAN, DATA, LTE |
| Button | Reset/WPS |
| Characteristics | Firewall: Filtering/ Port Mapping Local & Remote management |
